TrolMaster® Hydro-X, Environmental Control System (HCS-1)

TrolMaster Hydro-X Environmental Control System with 3-in-1 Sensor (HCS-1)

The Hydro-X system is a professional-grade single zone environmental system. It is fully customizable and modularly designed. Installation is simple and the system is easy to expand upon. The Hydro-X system can control most grow lights brands, HVAC systems, mini-split air conditioners, commercial dehumidifiers and humidifiers, as well as CO2 generators or regulators. With the free TrolMaster App, the user can access all of the settings and alerts on the system from anywhere at anytime.

The Hydro-X / HCS-1 system is a complete, professional-grade environmental system, designed to automatically control indoor and greenhouse environments. It is designed to be modular and fully customizable, optimized to control all devices within a single growing zone.

The HCS-1 comes standard with a multipurpose 3-in-1 Temperature / Humidity / Photocell sensor, the MBS-TH. The MBS-TH sensor, a CO2 sensor, smoke and water detectors can be daisy chained to the HCS-1 SENSOR port. Up to 5 smoke detectors and 5 water leak sensors can be connected.

There are 2 lighting control channels that control an unlimited number of lights on 2 separate channels. The system can operate two different lighting systems at the same time. The LCD display on the HCS-1 provides you with current conditions and access to all settings. Entering settings is easy to do by using the 6 buttons on the front of the HCS-1, or you can change settings remotely by using the FREE TrolMaster APP.

*The HCS-1 is the brain of the Hydro-X system. It comes with a 3-in-1 Temp/Humid/Photocell sensor.

*Internet Connection Note: TrolMaster's main controllers can be connected to the internet in order to use the available APP. Most internet services available including land-based and cellular internet are compatible. However, HughesNet / Viasat Satellite internet is NOT compatible with TrolMaster controllers at this time.

Data Record Note: The HCS-1 can record the data coming in from the sensors onto a CSV file. To use this feature, you must first insert a MicroSD card 32GB or less into the MicroSD slot on the bottom of the HCS-1 or NFS-1 controllers. Once the card is inserted, the unit will automatically store data so it can be viewed later.
